Page 37
4.3 Supply [X9]
Table 11: Technical Data: Performance data [X9]
Type ARS 2102 SE ARS 2105 SE ARS 2108 SE
Supply voltage 1 x 100 ... 230 VAC [± 10 %], 50 ... 60 Hz
In continuous operation maximum of
mains current
2,4 A
RMS
4,7 A
RMS
10 A
RMS
Intermediate circuit voltage (at an
operating voltage of 230 VAC)
310 ... 320 VDC
Alternative DC supply 60 ... 320 VDC
24 V supply 24 VDC [± 20 %]
(0,55 A)
*)
24 VDC [± 20 %]
(0,65 A)
*)
*)
plus current consumption of a possibly connected holding brake and I/Os
Table 12: Technical data: Internal brake resistor [X9]
Type ARS 2102 SE ARS 2105 SE ARS 2108 SE
Brake resistance
60  37 
Pulse power 2,4 kW 3,9 kW
Continuous power 10 W 20 W 25 W
Threshold limit 389 V
Over-voltage detection 400 V
Table 13: Technical data: External brake resistor [X9]
Type ARS 2102 SE ARS 2105 SE ARS 2108 SE
Brake resistance
 50   25 
Continuous power
 2500 W
Max. operating voltage (at output)
 460 V  400 V
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
