Page 38
4.4 Motor connection [X6]
Table 14: Technical data: Motor connection [X6]
Type ARS 2102 SE ARS 2105 SE ARS 2108 SE
Specifications for operation with 1x 230 VAC [± 10 %], 50 Hz
Output power 0,5 kVA 1,0 kVA 1,5 kVA
Max. output power for 5s 1,0 kVA 2,0 kVA 3,0 kVA
Output current 2,5 A
RMS
5 A
RMS
8 A
RMS
Max. output current for 5s 5 A
RMS
10 A
RMS
16 A
RMS
Max. output current 0,5s 10 A
RMS
20 A
RMS
32 A
RMS
(f
el
≥ 3 Hz) *)
Current derating from 12 kHz 12 kHz 10 kHz
Max. clock frequency 20 kHz (software programmable)
Holding brake 24 V Signal level dependent on switch status, high side / low side
switch / max. 2 A
Motor temperature sensor N.C. and N.O. contact, PTC, KTY …
+ 3,3 V / 5 mA
Power loss/efficiency
(with regard to the rated output
power)**)
typical 8% / 92%
*) with smaller electrical rotational frequencies (f
el
) shorter permissible times are valid for ARS 2108 SE
**) "As a guideline".
4.4.1 Current derating
The ARS 2100 SE series servo drives have a current derating during nominal operation. The rated
current and the time of the maximum allowed peak current of the servo drive depend on different
factors.
These factors are:
Output current level (the higher the output current, the shorter the allowed time)
Power stage clock frequency (the higher the clock frequency, the shorter the allowed time)
Electrical rotational frequency of the motor (speed multiplied by pole pair number; the higher the
rotational frequency, the longer the allowed time)
The last point (electrical rotational frequency) only applies to the ARS 2108 SE. For a better clarity, we
only distinguish between electrical rotational frequencies less than 2 Hz and those over 3 Hz. For
rotational frequencies lying in between these two values, interpolation is required.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
