Error message Meaning of the error message Measures
Main
index
Sub
index
7 SOS: SOS requested > 24 hrs Cause: If SOS is requested for more than 24
hours, the error is triggered.
Action: Terminate SOS and move axle at least
once during this time.
55 0 No actual rotational speed /
position value available or idle >
24 hrs
Cause:
 Subsequent error when a position
encoder fails.
 Safety function SSF, SS1, SS2 or
SOS requested and actual
rotational speed value is not valid.
Action: Check the function of the position
encoder(s) (see following error).
1 SINCOS encoder [X2B] -
Tracking signal error
Cause:
 Vector length sin²+cos² is outside
the permissible range.
 The amplitude of one of the two
signals is outside the permissible
range.
 Offset between analogue and digital
signal is greater than 1 quadrant.
Action: Error may occur with SIN/COS and
Hiperface encoders.
 Check the position encoder.
 Check the connection wiring
(broken wire, short between two
signals or signal / screening).
 Check the supply voltage for the
position encoder.
 Check the motor cable / screening
on motor and drive side – EMC
malfunctions may trigger the error.
2 SINCOS encoder [X2B] -
Standstill > 24 hrs
Cause: Input signals of the SinCos encoder
have not changed by a minimum
amount for 24 hours (when safety
function is requested).
Action: Terminate SS2 or SOS and move axle
at least once during this time.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
