Page 146
Error message Meaning of the error message Measures
Main
index
Sub
index
57 0 Error, I/O self test
(internal/external)
Cause:
Internal error of digital inputs
DIN40 ... DIN43 (detected via
internal test signals).
Error at brake output at X6
(signalling, detected by test pulses).
Internal error of brake output
(detected via internal test signals).
Internal error of digital outputs
DOUT40 – DOUT42 (detected via
internal test signals).
Action:
Check the connection wiring for the
digital outputs DOUT40 ... DOUT42
(short circuit, cross circuit, etc.).
Check the connection wiring for the
brake (short circuit, cross circuit,
etc.).
Brake connection: The error may
occur with long motor cables if:
1. The brake output X6 was
configured for the brake (this is
the case with factory settings!)
and
2. A motor without a holding brake
is used and the brake
connection lines in the motor
cable are terminated at X6. In
this case: Disconnect the brake
connection lines at X6.
If there is no error in the connection
wiring, there may be an internal
error in the module (check by
swapping the module).
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
