Joystick operation
General remarks
For joystick operation the controller is working independent
from a host control unit (subject the controller settings must
not be changed)
Motor moving is controlled from the deflection of the joystick
axes, this a
llows a very sensitive and intuitive positioning of
the motors.
Joystick axes assignment
The axis of the joystick are assigned to the axis of the control-
ler as follows:
Figure 4: FJ Joystick with speed buttons
Joystick axes Controller axes
X-Knob Axis-1
Y-Knob Axis-2
Z-Knob Axis-3
+X-X
+Y
-Y
Z
