Manual Corvus-eco
Functions 54
Analog encoder interface with sin/cos module
Each axis can be supplied with a sin/cos module. This module
is a independent hardware data interface for sinusoidal
encoder signals. The input signal is internal multiplied.
The modules are available with a 12 Bit or 16 Bit data acqui-
sition in
terface.
Technical data:
To calculate the maximum positioning resolution of the
sin/cos module, the cycle time of the measurement signal pe-
riod must
be divided by the multiplication factor.
The driver electronics supports a resolution up to 1nm
Input signal 1Vpp, differential
Reference mark
1 Vpp, differential
Max. input frequency 500 kHz
Multiplication factor
of signal interpolation
12 Bit module: 12,865
16 Bit module: 205,884
Option
Option
