Manual Corvus-eco
Functions 64
Output circuit
The output driver has a darlington circuit with open-collector
output which is also qualified for switching inductive loads.
The maximum current capacity of each output is 500 mA.
The total output current of all outputs may not exceed
100
0 mA.
Related Venus-1 commands:
Command Description
setout
generates signal output
getin input signal detection
setinfunc
safety function configuration
Output
SPNG
Load
Vcc
5V - 35V
