Manual Corvus-eco
Functions 50
Positioning with the joystick
The joystick mode allows a very sensitive positioning of the
axes with an analog joystick.
This movement is velocity controlled and caused by the de-
flection of the joystick.
The larger the deflectio
n, the larger the velocity. In joystick
mode the axes can be moved independently.
The position resolution with the joystick is enormous.
The internal calculation works with 32 bit and reaches
a resolution of theoretically 23
.2 fm (femtometer).
Joystick button speed
The two parallel wired push buttons of the joystick can switch
to a freely definable second joystick velocity.
This velocity is valid as lon
g as one of the buttons are
pressed.
Relevant commands:
Command Description
setjoyspeed max. joystick velocity
valid for all axes
setnjoyspeed max. joystick velocity
each axis separately
setjoybsp
eed max. joystick velocity if button is pressed
valid for all axes
setmanaccel manual acceleration
valid for all axes
