Manual Corvus
Releasing options 78
Option index table
With the command getoptions the already released
options are replied as a bit coded decimal number from
0 to 1023 as shown in the following table.
Example:
Options: 3 rd. Axis, Input/Output
getoptions = 8 +
1 = 9
Option
getoptions
Index
Bit
3 rd. Axis 1 D0
not used 2 D1
not used 4 D2
Input / output 8 D3
not used 16 D4
not used 32 D5
Closed loop axis 1 64 D6
Closed loop axis 2 128 D7
Closed loop axis 3 256 D8
High speed 512 D9
TABLE 2: Option index table
