Micos Corvus ECO - RS-232 Service Interface

Manual Corvus-eco
Connectors 92
RS-232 Service interface
Pin Name Function
1 nc nc
2 RxD Corvus Data input
3 TxD Corvus Data output
4 DTR Connected with Pin6
5 GND
6 DSR Connected with Pin4
7
8
9
TABLE 9. RS-232 service interface
RS-232 / Service
