85
Fit the shock absorbers in the 2 hubs, fix them with a nut and washers
(set screw 25N/m)
Fit together the 2 transmissions on the axles of the
changer bridge.
Fit the lengther on the variator side.
Fit the hose Ø 10 with 2 collar clips.
Fit the banjo of the brake hose with a copper joint
on each side and fit it with its screw on the brake caliper.
Fit the lower ball joint on the hub and fix it with 3 screws and
3 washers (screw fitted on the brake)
(set screw 10N/m).
