204 Chapter 22: Events (Automation)
PRO1 Live Audio System
Operator Manual
Table 7: Incoming event options
Table 8: Description of all event option parameters
When ... (from top list downwards) Then do this... Event
Parameters
(from top list
downwards)
Any IO Box,
IO ID1 to IO ID
18
Any MIDI
Channel,
Channel 1 to
Channel 16
Note Off,
Note On,
Aftertouch,
Pressure,
Control Change,
Program
Change,
Pitch Wheel
Midi TX
GPIO TX
Last
Next
Now
Jump
Notes Event
X-Fade Event
For details, see
Table 6 “Outgoing
event options” on
page 203
Parameter Description
Aftertouch How hard a key is pressed after it has been touched, that
is, it changes the pressure after the note has been hit.
Typically, aftertouch is useful for adding tremolo or vibrato
effects to a sound, just as a violin can add volume or pitch
changes to a sustained note using finger vibrato or addition
bowing intensity.
Parameters for Aftertouch are notes A0 to C7, with each
having a possible pressure of between 0 and 127. You can
also choose between Enable MIDI Byte 1 and Enable
MIDI Byte 2.
Any IO Box The trigger can be on any IO port of any IO box.
Any MIDI Channel Any of the MIDI channels.
Channel n One of the 16 MIDI channels.
Closure n Provides a contact closure that can be programmed to open
or close in response to a MIDI event.
Control Change Select the control changes that can be applied to a note in
progress. For example, by altering the volume (not
velocity) or adding sustain to a note (holding it for longer).
Parameters are All Notes Off and Reset All. You can also
choose between Enable MIDI Byte 1 and Enable MIDI
Byte 2.
FOH MIDI PORT The trigger is via the MIDI port of the FOH DL251/DL252
Audio System I/O.
GPIO TX Selects a GPIO event.
IO IDn The trigger is via a specific IO port.
Jump Opens a specified scene on the PRO1.
Last Opens the last (previous) scene on the PRO1. This scene is
the same one that would be opened if you pressed the last
button.
MIDI TX Selects a MIDI event.
