Typical configurations 237
PRO1 Live Audio System
Operator Manual
Monitor Mix
The following table shows the delay compensation settings for this mix.
The following example signal paths all measure the same latency of 300 samples @
96kHz = 3.125 ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST- MTX – XLR
• XLR – IP – AS – XLR
• XLR – IP – AS (With GEQ) – XLR
• XLR – AS DI – AS – XLR
• XLR – AS DI – AS (With GEQ) – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST (With GEQ) – XLR
• XLR – AR (Input) – MTX (With GEQ) – XLR
• XLR – AR (Input) – MAST - MTX - XLR
• XLR – AR (Input) – MAST - MTX (With GEQ) - XLR
Option On/off status
Master to Matrix Post-processing Off
Input Channels
Insert Off
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FX-Return
Graphic EQ
On
On
Off
On
Master and Matrix
Insert
Graphic EQ
On
On

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
