Midas PRO1 User Manual

238 Chapter 28: Delay Compensation (Latency)
PRO1 Live Audio System
Operator Manual
Monitor Mix (Low Latency)
The following table shows the delay compensation settings for this mix.
Input Ch Insert (OFF)
Aux Insert (OFF)
Aux Send & Return (OFF)
Aux GEQ (OFF)
Masters / Matrix Insert (OFF)
Masters / Matrix GEQ (OFF)
Master to Matrix tap-off = pre-processing.
Aux alignment (OFF)
The following example signal paths all measure the same latency of 172 samples @
96kHz = 1.79 ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST- MTX – XLR
• XLR – IP – AS – XLR
• XLR – AS DI – AS – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST - MTX - XLR
Option On/off status
Master to Matrix Post-processing Off
Input Channels
Insert Off
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FX-Return
Graphic EQ
On
Off
Off
Off
Master and Matrix
Insert
Graphic EQ
Off
Off

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
