Midas PRO1 User Manual

About the Patching screen 53
PRO1 Live Audio System
Operator Manual
Sidechains tab — To
The Sidechains tab allows patching to the
compressor and gate of the input and output
sidechains.
Effects tab — To
See “Effects tab — From” on page 50.
Mon. (Monitor) tab — To
The Mon. (Monitor) tab allows routing to
the communications and monitors.
This tab can opened using the src buttons
on the Monitors screen.
Mon. tab input Equivalent on the Monitors screen
Talk Input Source talk input
Talkback Input Source talkback input
Ext Input Source L external input L
Ext Input Source R external input R
PFL Direct Input Source pfl direct input

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
