About the Patching screen 55
PRO1 Live Audio System
Operator Manual
Common device features
The device images have certain common features in their layout, as highlighted in the
following diagram, which shows one of the I/O devices.
Mic Splitter DL431 Mic Splitter.
Line IO DL451 Modular I/O.
Generic AES50 Audio-only device that is used to
represent the inputs and outputs of
any third party AES50 device.
DN9696 Klark Teknik DN9696 Recorder. Use
up to four of these devices (with IDs
1 to 4) to represent the four AES50
ports for up to 96 channels of
recording/playback.
For more information, go to our
website www.klarkteknik.com.
DL351A One of four devices that comprise the
DL351 Modular I/O. The others are
“DL351B”, “DL351C” and “Dl351D”
(not displayed). For more
information, go to our website
www.midasconsoles.com.
None-Unknown Selects no device. N/A
Device type Description Diagram
