Adding and dispensing chemical agents
53
Rinsing agent
Rinsing agent is necessary to ensure water does not cling to and
leave marks on items, and to help items dry faster after they have
been washed.
Residues of rinsing agent remain on the surface of items after
they have dried.
It is important to check the suitability of the rinsing agent being
used.
When reprocessing ophthalmic instruments do not dispense
rinsing agent.
Rinsing agent is automatically dispensed in the Final rinse phase. The
reservoir must be filled for this to occur.
Adding rinsing
agent
Do not fill with cleaning agent.
This would damage the reservoir.
Only fill the rinsing agent reservoir with rinsing agent for washer-
disinfectors.
Open the door fully.
Unscrew the yellow lid with the symbol in the direction of the
arrow.
The reservoir holds approx. 300ml.
