Miller Multimatic 220 User Manual

OM-281426 Page 22
F
Complete Parts List is available at www.MillerWelds.com
5-7. Generator Requirements
Generator settings, if applicable

A complete Parts List is available at www.MillerWelds.com
OM-281426 Page 11
2-4. Generator / Inverter Requirements
Engine Control Switch must be set
at "RUN" position - not "RUN/
IDLE".
Set generator Fine Adjustment
Control to 10 for maximum auxili-
ary power.
Minimum auxiliary power requirement at
rated load is 10 KW continuous/12.5 KW
peak at 240 volts AC for full output. Smaller
generators will reduce output capability.

Miller Multimatic 220 Specifications

General

Input Voltage	120/240 V
Amperage Range	30 - 230 A
Weld Thickness - Stick	16 ga. - 3/8 in.
Input Hz	50/60 Hz
Processes	MIG, TIG, Stick
Weld Thickness - MIG	24 ga. - 3/8 in.
Input Phase	1-Phase
Weight	56 lb
