PRODUCT INFORMATION
Chapter 3 PRE INSTALLATION
3-1 INSTALLATION REQUIREMENTS
FEEDWATER REQUIREMENTS
Type of Feedwater Elix, RO, distilled or DI water
Flowrate ≥ 1.5 LPM (Litres per minute)
Minimum Pressure > 0 bar (Feed from a tank)
Maximum Pressure ≤ 0.5 bar
Temperature 5 to 35 °C
Conductivity < 100 μS/cm
TOC < 50 ppb
NOTE: If the feedwater pressure is greater than 0.5 bar, then the Pressure Regulator
(ZFMQ000PR) is required.
F
EEDWATER CONNECTION NEEDED
Feedwater Piping Connection 1/2 inch Male GAZ, NPTM or BSPM
ENVIRONMENTAL REQUIREMENTS
Indoor Use Only
Storage Temperature 5 °C < T < 40 °C
Operating Temperature 5 °C < T < 40 °C
Relative Humidity
Should not exceed 80% for temperatures below 31 °C
Should stay within 50% to 80% between 31 °C and 40 °C.
Altitude < 3000 metres
Installation Category II
Pollution Degree 2
3-2 OPTIONAL EQUIPMENT YOU MAY NEED
WALL MOUNTING BRACKET
The Millipore Catalogue Number for the Wall Mounting Bracket is WMBSMT002. The mounting
hardware for attaching the bracket to a wall is not included and must be supplied.
- 6 -
