( P602 cont’d )
values ( P600 = 7 ):
index value
1 notch angle
α
2 discharge coefficient Ce
BS-3680 Thin Plate V Notch Weir
transducer *
4 to 5 x h
max
* The transducer must be above the maximum head by at least the blanking value, P-800.
