P603 (G) MAX HEAD
Enter the head value associated with Max Flow, in Units (P004).
values: -999 to 9999 (preset = Span, P007 value)
P604 (G) MAX FLOW
Enter the flowrate associated with Max Head, in any flowrate units (flowrate
units = volume units / time units) using the Time Units (P606).
e.g. If flowrate is to be displayed in 1000’s of L
3
/ day, and the maximum
flowrate is 376,500 L
3
/ day, enter 376.5.
values: -999 to 9999 (preset = 1000)
P605 (G) ZERO HEAD
Enter the distance above Empty (P006) in Units (P005) representing zero
head (and flow).
This feature is used for weirs and flumes (e.g. Palmer Bowlus) whose zero
reference is at a higher elevation than the channel bottom at the point
of measure (transducer location).
values: -999 to 9999 (preset = 0.000)
P606 (G) TIME UNITS
Enter the Time Units to be used in conjunction with volume units to
derive the desired flowrate units as entered for Max Flow (P604).
This parameter is used only for ratiometric calculations. For devices that
support absolute calculations (P600 = 6 & 7), the time interval is defined
by OCM units (P608).
values: 1 = seconds
2 = minutes
3 = hours
4 = days (preset)
( e.g. litres /
second, enter 1)
PL-507 114
