P007 SPAN
Enter the maximum surface distance from Empty (P006).
Span is automatically preset to 1.1 x the blanking value (P800) less than
the Empty value, unless it is altered manually.
For "distance" Operation (P001=3), Span is preset to Empty (P006).
Enter a lower value if desired. If the automatic setting is not high enough,
(see Transducer). Always prevent the monitored surface
from entering the blanking zone.
values: 0.000 to 9999
With the Quick Start Parameters altered as
required, proceed to to
identify / verify system performance
P008 (G) DATE
Enter the current date in YY.MM.DD format.
values: 00.00.00 to 99.12.31
Year 2000 Compliance
The year is stored and displayed as a 2 digit number
from 00 to 99. Year values less than 69 are 21st
century (2000 – 2069). Year values greater than
70 are 20th century (1970 – 1999).
P009 (G) TIME
Enter the current time in HH.MM.SS (24 hour) format.
values: 00.00.00 to 23.59.59
OPERATION
INSTALLATION
PL-507 64
