iii
Miscellaneous Settings .........................................3-34
Switch the display language ....................................3-34
Other Convenient Settings ......................................3-35
Reset the setting values to the initial state. .............3-41
CHAPTER 4 In Case of Trouble
Before taking a phenomenon as a trouble ..............4-2
Troubles for which error messages are given
on the LCD .............................................................4-4
Error message ...........................................................4-4
Status message ........................................................4-6
CHAPTER 5 Appendix
Specifications of the main unit ................................5-2
Repeatability condition ..............................................5-3
Cutter blade ............................................................5-4
Replacing the cutter blade ........................................5-4
Adjusting the cutter blade ..........................................5-5
Replacing the blade of any cutter other than that
supplied with the plotter ............................................5-5
Note slip .................................................................5-6
Function Flowchart .................................................5-7
Functions invoked with the specific keys ..................5-7
Functions invoked with the jog mode (jog keys) .......5-9
Functions .................................................................5-10
