Cleaning and Disinfection Maintenance
9 - 26 Operator’s Manual of Anesthesia System
Figure 9-33 Insert the O
2
sensor cable
5. Close the O
2
sensor cover. The O
2
sensor is now fully Installed.
9.7.3.4.9 Manual bag
Directly insert or draw out the manual bag to install or disassemble it.
Figure 9-34 Install the manual bag
9.7.3.4.10 Breathing Tube
NOTE: When installing a breathing tube, hold the joints at both ends of the
tube to prevent damage to the tube.
NOTE: Do not reuse the bacteria filter repeatedly to prevent cross infection.
NOTE: Install the filter following the instructions in this manual to prevent
dust or particles from entering the patient's lungs and prevent cross
infection.
CAUTION: The bacteria filter shall comply with the requirements of ISO 23328-1
and ISO 23328-2.
