Operator’s Manual of Anesthesia System 9 - 27
Maintenance Cleaning and Disinfection
1. Install the expiratory tube and inspiratory tube to the expiration connector and the inspiration
connector of the breathing system, respectively.
Figure 9-35 Install the breathing tubes
2. Install the bacteria filter onto the Y-piece.
Figure 9-36 Install the bacteria filter
9.7.3.5 Check Before the Next Use
After reassemble the components of the breathing system, power on the Anesthesia System and
follow the on-screen prompts to perform leak test and compliance test. See Section 5.4.2 "Leak &
Compliance Test".
9.7.4 Negative Pressure Suction Device
9.7.4.1 Disassembly
NOTE: Disassemble the Negative Pressure Suction Device at the point of use or
at the designated cleaning area.
To disassemble the negative pressure suction device, pull out the suction tube and discard the filter.
Breathing tubes
Breathing tubes
bacteria Filter
