Cleaning and Disinfection Maintenance
9 - 28 Operator’s Manual of Anesthesia System
Figure 9-37 Disassemble the negative pressure suction device
NOTE: Filters are disposable accessories. Please follow local regulations to
dispose of discarded filters.
9.7.4.2 Cleaning
1. Submerge or rinse the suction tube in an authorized cleaning agents (See Table 9-3 "Manual
Cleaning Agent" on Pages 9-9) for the required period as specified by the manufacturer of the
cleaning solution.
2. Rinse the suction tube with the clean water.
3. Completely dry the suction tube before use.
4. To disinfect the suction tube, proceed to 9.7.4.3 Disinfection. Otherwise, jump to 9.7.4.4
Reassembly.
9.7.4.3 Disinfection
NOTE: Before the disinfection, make sure that the suction tube has been
cleaned following 9.7.4.2 Cleaning.
1. Submerge or rinse the suction tube in an authorized disinfectors (See Table 9-4 "Manual
Disinfector" on Pages 9-10) for the required period as specified by the manufacturer of the
disinfecting solution.
2. Rinse the suction tube with the clean water.
3. Completely dry the suction tube before use.
9.7.4.4 Reassembly
NOTE: Before the reassembly, make sure that the assembly has been
reprocessed and dried.
NOTE: Reassemble the Negative Pressure Suction Device at the point of use
and at the designated cleaning area.
1. Place the liquid collection bottle to the bracket. Connect the suction tube and the filter
following the screen printed instructions.
2. Insert the suction tube to the overfill protection connector. The negative pressure suction
device is now fully installed.
Filter
Suction tube
Overfill protection connector
To Next Page
