BeneVision N Series Patient Monitor Operator’s Manual A - 33
Specifications of parameters monitored when using with the mainstream CO
2
module
Specifications of parameters monitored when using with the sidestream CO
2
module or AG module configured with
the paramagnetic oxygen sensor
Pplat 0 to 120 cmH
2
ONot specified.
Compl 0 to 200 ml/cmH
2
O
RSBI 0 to 4095 rpm/L
NIF -20 to 0 cmH
2
O
WOB 0 to 10J/L
RAW 0 to 100 cmH
2
O/(L/s) Not specified
Parameter
Measurement range Measurement accuracy
VCO
2
0 to 200 ml ±15% or ±15 ml, whichever is greater
Parameters
Resolution
Parameters
Resolution
Parameters
Resolution
VCO
2
1 mL MVCO
2
1 mL/min FeCO
2
0.1%vol
SlopeCO
2
0.01%vol/L Vtalv 1 mL MValv 0.01 L/min
Vdaw 1 mL Vdaw/Vt 1% Vdalv 1 mL
Vdalv/Vt 1% Vdphy 1 mL Vd/Vt 1%
Parameter
Measurement range Measurement accuracy
VCO
2
0 to 200 ml ±15% or ±15 ml, whichever is greater
VO
2
0 to 200 ml ±15% or ±15 ml, whichever is greater
Parameter
Resolution
Parameters
Resolution
Parameters
Resolution
VCO
2
1 mL MVCO
2
1 mL/min VO
2
1 mL
MVO
2
1 mL/min EE 1 kCal/day RQ 0.01
Alarm limit Range Step
PEEP High PEEP≤50 cmH
2
O: (low limit + 1) to 50 cmH
2
O
PEEP>50 cmH
2
O: (low limit + 5) to 120 cmH
2
O
PEEP≤50 cmH
2
O: 1 cmH
2
O
PEEP>50 cmH
2
O: 5 cmH
2
O
PEEP Low PEEP≤50 cmH
2
O: 0 to (high limit - 1) cmH
2
O
PEEP>50 cmH
2
O: 50 to (high limit - 5) cmH
2
O
PIP High PIP≤50 cmH
2
O: (low limit + 1) to 50 cmH
2
O
PIP>50 cmH
2
O: (low limit + 5) to 120 cmH
2
O
PIP≤50 cmH
2
O: 1 cmH
2
O
PIP>50 cmH
2
O: 5 cmH
2
O
PIP Low PIP≤50 cmH
2
O: 1 to (high limit - 1) cmH
2
O
PIP>50 cmH
2
O: 50 to (high limit - 5) cmH
2
O
MVe High Mve≤10 L/min:(low limit + 0.5 L/min) to 10.0 L/min
Mve>10 L/min: (low limit + 2 L/min) to 60.0 L/min
Mve≤10 L/min: 0.5 L/min
Mve>10 L/min: 2 L/min
MVe Low Mve≤10 L/min: 0.5 L/min to (high limit - 0.5 L/min)
Mve>10 L/min: 10 L/min to (high limit - 2 L/min)
