Mindray DC-8

9-14 Structure and Assembly/Disassembly
9.3.6.3 DVR Board
Put the digital board assembly with button cell downwards and release DVR board retainer,
and then remove DVR board.
NOTE:
When assembling COME module to the digital board, please take the following sequence:
first assemble the radiator to the CPU board and then assemble the COME module to the
digital board, the fan assembly comes last to prevent the fan from damage. Align the
COME module to the board connector and slightly change the position to allow the CPU
board connector connects the digital board connector, and then push the radiator
moderately to make the plug and socket connect with each other fully.
