Mindray DC-8 Service Manual

Structure and Assembly/Disassembly 9-5
7. Unscrew 8 M4X12 screws fixing probe board assembly and pull it out.
9.3.3 Hard Disk Assembly
NOTE
Please pay attention to the following matters during
disassembling/assembling, otherwise the hard disk will be damaged:
 Hold the side of the hard disk, and please do not touch the board
of the hard disk.
 Fasten the screws with the handy screw driver, and do not with
the electric screw driver.
 The torsion value of the screw lock is:
M3: 4 to 6 kgf.cm
M4: 6 to 8 kgf.cm
