9-42 Structure and Assembly/Disassembly
19. Do cable alignment as per required in the following picture for other cables.
20. Connect 3 cables to corresponding sockets in the minor panel assembly.
21. Rotate minor panel assembly, put the minor panel assembly on the cast-aluminum base, align
cables as per the right picture in the following.
Multiple encoder cables
To Next Page
