Optional Installation/Assembly 10-5
4. If there is pencil probe wire on ECG module, plug the wire into the socket on the side of probe
board assembly and fix it on the cable tie bridge of shield cover of probe board by one piece of
cable tie.
5. Refer to procedure 1 to remove front cover of the main unit and then reversely assemble the
cover, printer cover and storage box cover. Assembly is finished.
If the front board USB&ECG and pencil probe port assembly is configured already,
please check the panel appearance for further operation.
