Operator’s Manual 13 - 1

13Probes and Biopsy

13.1 Probes

Probe model Probe Type Probe Figure

7LT4s Linear

L14-6s Linear

C4-1s Convex

C5-1s Convex

P10-4s Phased

P7-3Ts Phased

L14-6Ns Linear
