2 System Overview
Operator’s Manual 2 - 25
–B+M
–B+PW/CW
– B+Color+PW/CW
– B+Power+PW/CW
The image magnification factor value will display in real time in the image parameter area.
2.10.10iZoom (Full Screen View)
This feature magnifies the image area in full screen for a better observation.
Exit iZoom button : Select to exit full-screen zoom status.
2.10.11Freeze/Unfreeze the Image
Select [Freeze] to freeze a scanning image. In freeze mode, the probe stops transmitting acoustic
power, and all images and parameters are frozen.
After freezing an image, the system may enter cine review, measure, comment adding, body mark
mode or current mode, depending on what has been preset.
Select [UnFreeze] in freeze mode to unfreeze the image, and the system continues image scanning.
2.10.12Imaging Mode Switching When Frozen
Imaging mode switching in freeze mode follows these principles:
• In splitting display B mode, Select each image window to switch between the windows.
• In freeze mode, the system supports imaging mode switching between the sub-modes (only for
the activated window). For example, if the frozen image is in B+Color+PW mode, the system
supports imaging mode switching between B+Color+PW, B+Color, B+PW and B by selecting
[Color] or [PW].
2.11 Cine Review
After selecting [Freeze], the system allows you to review and edit the images prior to the image
being frozen. This function is called cine review. You can perform zoom, measurements, add
comments and body marks on the images being reviewed.
The system supports manual review as well as automatic review.
In addition, the system supports the images reviewed along with physiological waveforms, if the
detection of physiological waveforms is performed.
• Cine Review images can be inadvertently combined in-between separate
patient scans. The Cine Review memory must be cleared at the end of the
current patient exam and before starting the next new patient exam by
selecting [End Exam] on the touch screen.
