2 System Overview
Operator’s Manual 2 - 27
2.11.3 Auto Review
Reviewing all
Perform the following procedure:
1. In manual cine review status, Select to activate auto cine review.
2. Review speed: in auto cine review status, drag the mark to select different speeds: 1/10x, 1/5x,
1/4x, 1/3x, 1/2x, 1x, 2x, 3x.
3. In auto play status, Select to stop auto play.
Setting the Auto Review Region
You can set a segment of cine loop which can be reviewed automatically. After the auto review
region is set, the auto cine review can only be performed within this region; but the manual cine
review can be performed beyond this region.
Perform the following procedure:
1. Set first frame: drag the start mark to the frame as start point.
2. Set end frame: drag the end mark to the frame as end point.
3. Select to start play and select the speed.
4. Select to end auto play.
When the cine file is saved, only images within the auto review region are saved.
2.11.4 Linked Cine Review
Linked cine review reviews images captured at the same moment.
• B/Color/Power/TVI/TEI dual live
•B/B dual live
• B+M synchronization mode
• B+PW/TVD duplex mode
• TVM, CM triplex mode
The frame synchronization mark on the time mark of M/PW image indicates the corresponding
2D image and M/PW image. In statuses other than dual live status, you can only review images in
the currently active window.
2.12 Image Compare
2.12.1 Image Compare in Review Mode
For B/B+COLOR/B+TVI/B+POWER/B+TEI mode image, you can select at most 4 images; for
PW/M/CW/TVD mode image, you can select at most 2 images
Perform the following procedure:
1. Select [Compare Items] on iStation screen or Review screen.
2. Select the images for comparison.
