Mindray Eagus TEX21 - Orientation of the Ultrasound Image and the Probe Head; Procedures for Operating

13 - 6 Operator’s Manual
13 Probes and Biopsy
13.1.2 Orientation of the Ultrasound Image and the Probe
Head
The orientation of the ultrasound image and the probe are shown as below. The “M” side of the
ultrasound image on the monitor corresponds to the mark side of the probe, for the laparoscopic
probe, the probe orientation starting side is located on the end of the distal tip away from the
handle. Check the orientation before the examination (Using a linear probe as an example).
13.1.3 Procedures for Operating
WARNING
Disinfect the probe and sterilize the needle-guided bracket before and after an
ultrasound-guided biopsy procedure is performed. Failure to do so may cause
the probe and the needle-guided bracket becomes a source of infection.
This section describes general procedures for operating the probe. The proper clinical technique to be
used for operating the probe should be selected on the basis of specialized training and clinical
experience.
4. Probe connector Connects the probe and cable to the ultrasonic diagnostic
system.
No. Item Description
1Orientation mark
2Mark
1
2
