B Wireless Charging
B.1 Air Station Installation
The Air Station is installed in three ways:
• Method A: Ground installation by quick-disassembly;
• Method B: Ground installation with guide plate;
• Method C: Wall mounting installation.
B.1.1 Installation Preparation
Installation tools: Phillips screwdriver, percussion drill, tape measure, hammer, marking pen, pad
(required in special installation environment), and steel nails (required in special installation
environment)
Item list: Check if the items are complete according to the installation method. If not, please contact
Mindray Customer Service Department or sales representative.
B.1.2 Installing the Pad
Observe the wall and measure the distance (d) of the skirting line. If the thickness is larger than 12
mm, install a pad. see “Figure B-1 Wall Type” to confirm the wall type.
No. Name Quantity Remarks
1. Transmitting Module 1 For A/B/C installation
methods
2. Base 1 For A/B installation methods
3. M3X6 Cross recessed
countersunk head screws
2 For A/B installation methods
4. Foot pad 2 For A/B installation methods
5. Thin cushion pad 2 For A/B/C installation
methods
6. Thick cushion pad 2 For A/B/C installation
methods
7. Guide plate 1 For B installation method
8. Wall mounting bracket 1 For C installation method
9. Expansion rubber stopper 6 For C installation method
10. Tapping screws 6 For C installation method
11. Power cable 1 For A/B/C installation
methods
12. Velcro 1 For A/B/C installation
methods
