13 - 48 Operator’s Manual
13 Probes and Biopsy
NGB-054 metal-needle detachable needle-guided bracket
1 Angle adjusting block
2 Angle locking nut
3 Right clamp of the bracket
4 Left clamp of the bracket
5 Needle clamping cover
6 Needle-shaped adjusting nut
7 Locking nuts of the guided bracket at the
right and left sides
1
2
3
4
5
6
7
8
9
10
