2 System Overview
Operator’s Manual 2 - 9
7. AC power cord Retractable AC power cord.
8. Air Charge Module Configured with the air station to charge the main unit.
9. Battery pack Supply power without AC power supply.
10. Storage bin Used for keeping the cases, towelette, etc.
11. Trolley back handle
Used for moving the trolley.
12. Probe ports Connects a probe to the main unit.
13. Touch screen and display Operator-system interface or control; displays the image and
parameters during the scan.
14. Height adjustment lever Press to adjust the height of the stand.
15. Trolley rear handle
Used for ascending/descending the trolley or moving the
trolley.
16. Front storage bin Used for keeping the cases, towelette, etc.
17. Printer bracket Used for placing the printer.
