4 Setup
Operator’s Manual 4 - 15
2-dimension barcode reader (2D)
• General Analysis Mode
Select “General” from “Analysis Mode” drop-down list: The scan codes consist of Patient ID,
Other ID, Patient Name, Birth, etc.
Default Item If the default item is set to “No”, and both the 2D and 1D barcodes fail to be
matched, the obtained data of the barcode is input as a string of characters.
After selecting a default item from the drop down list of “Default Item”, the
obtained data of the scanned barcode will be displayed in the corresponding
selected default item.
For example, if the default item is set to “Patient ID”, and both the 2D and
1D barcodes fail to be matched, the obtained data is displayed in the “Patient
ID” item in Patient page automatically.
Service Query • Select a service query. For example, select “Worklist server” from the
drop-down list, and the system searches the Worklist server according to
the scanned data.
• Select “No” from the drop-down list, and the system creates a new exam
in the Patient page according to the scanned data.
Default Query
Item
• Select a default item for searching the service query.
For example, users select “Patient ID” from the drop down list of
“Worklist Default”, and the system searches Patient ID in the Worklist
server.
• Select “No”, and the system searches the Worklist server in the priority
order: “Patient ID” > “Last name” > “Accession #”.
NOTE:
The matching priority order is 2D item, 1D item, and Default Item, after
the 1D/2D and default items are configured.
Import/Export Import and export configuration files to preset the barcode. For details,
please contact the service engineer.
Item Description
Item Description
Scan Barcode Example Input a barcode example, barcode example is separated by separators
(the separator is used to set the start and end position of each item), and
the barcode data is displayed in the following items in turn.
