Mindray MX7

16 Probes and Biopsy
Operator’s Manual 16 - 37
a. Hold the probe. Press the biopsy needle to separate the needle from pressure position of
the needle.
b. Separate the bracket and the probe from the needle.
5. Remove the needle-guided bracket:
a. Rotate the clamping nuts of the needle guided-bracket on right and left side (following the
direction of the arrow). The needle guided-bracket is separate from the probe.
b. Hold the probe and take out the bracket.
NGB-025 Metal-needle undetachable needle-guided bracket
1Pinch nut
2 Intra-cavity probe
3 Lower clamp
1
2
34
5
678
