Mindray MX7 User Manual

2 System Overview
Operator’s Manual 2 - 15
2. CW CW mode button Enters CW mode.
iTouch iTouch button • Press to enter iTouch mode.
• Long press to exit iTouch mode.
3. M M mode button Press to enter M mode.
4. PW PW mode button Press to enter PW mode.
5. Measure Measure button Press to enter/exit application measurement.
6. Update button Switching key: Press to change the currently
active window.
Start or end capturing the image in iScape/Smart
3D.
7. Caliper Caliper button Press to enter/exit general measurement.
8. C Color mode button Press to enter Color mode.
9. B B mode button Press to enter B mode.
10. P Power mode button Press to enter Power mode.
11. Dual-split window
button
Press to enter the Dual mode from another mode.
Press to switch between the two windows in the
Dual mode.
12. Image zoom Press to enter or exit zoom status.
13. iTouch/Gain Gain and iTouch
knob
Adjust the gain of the image in various modes.
• Press to enter iTouch mode.
• Long press to exit iTouch mode.
Gain Gain knob Adjust the gain of the image in various modes.
14. Depth Depth adjustment
button and
functional interface
Adjust the depth parameter when the indicator is
on.
15. Save static image
button
Save images in a preset way.
16. Freeze button Press to freeze or defreeze the image.
17. / Confirm key (right
<Set> key)
Press to confirm the operation.
18. / Trackball To move the cursor.
/
Trackpad To move the cursor; tap to confirm the operation.
19. / Confirm key (left
<Set> key)
Press to confirm the operation.
No. Name English Name Description

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
