V Hub
Mech
anical F
unctions
4 - 20
V Series Operating
Instructions
4.5.7
V Hub Status Indicators
The V Hub is connected to the
V 12/V 21
via cab
le. The indicator light at t
he base of the rack
(shown
in FIGURE 4-34) designates the status of the V Hub.
FIGURE 4-34
INDICATOR LIGHT C
OLOR
STATUS
No light
No com
munication, V Dock disconnected
Amber
Pow
er on but V Hu
b is not communicating
Green
Power on and V Hub is communicating
V Dock Indicator Light
104
106
