Addendum to V Series Operating Instructions 1 - 11

Continuous Cardiac Output (CCO) & Continuous Hemodynamics (Optional) Digital Tiles

1.4.5 CCO STAT Digital Tile Layout

The CCO STAT digital tile displays:

1. CCO STAT value

2. Message area

3. CCI STAT value

4. CCI STAT alarm limits

5. T Blood alarm limits

6. Units of measure

7. T Blood value

8. SVR or SVRI value

9. SVR or SVRI alarm limits

10. CCO STAT alarm limits

FIGURE 1-7 Ex

ample CCO STAT Digital Tile (with SVR enabled)

1.4.6 About the CCO STAT Tile

• The CCO STAT tile displays all CCO STAT in units of l/min with a resolution of 0.1 l/min.

• If the CCO STAT measurement is invalid, “- -” displays in place of digits.

1.4.7 CCO Alarms

Refer to the "Configuring CCO/Hemo Alarms" on page 1-4 for additional information.
