Specifications Product Specifications
29 - 8 V Series Operating Instructions
29.1.6 V Hub Safety Designations:
29.1.7 12 Lead ECG Safety Designations:
TABLE 29-6
Type of protection against electric shock: Class II
Supply Connection: +12 VDC, +5 VDC from monitor
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between equipment
and patient
Equipment designed for direct electrical and non-
electrical connection to the patient
Degree of Mobility: Portable
Maximum Size: 10"H x 8"W x 5"D
Maximum Weight: 3.0 lbs
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1 - Lock control
1 - Indicator light
Interfaces: 1 - V 12/V 21 Connector
TABLE 29-7
Type of protection against electric shock: Class II
Degree of protection against electric shock: ECG- Type CF defibrillation protected
Supply Connection: +3.3 VDC from VPS
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids: Splash Proof (IPX4)
Degree of electrical connection between
equipment and patient
Equipment designed for direct electrical connection to
the patient
Degree of Mobility: Portable
Maximum Size: 1.1"H x 2.6"W x 4.6"D
Maximum Weight: 1.02 lbs.
