9-76
9.5.1.2 Board List
S/N Description P/N
B1 0623 motherboard PCBA 051-000765-02
B2 0621 electronic flowmeter PCBA 0621-30-69351 (three flowtubes
configured)
0621-30-78639 (two flowtubes
configured)
0621-30-78638 (one flowtube
configured)
B3 0623 toplight board PCBA 051-000764-00
B4 0616 monitored signal detection board 051-003166-00
B5 0621 power board 0621-30-78595
B6 0621 main control board 9210-30-30150
B7 0623 battery conversion board PCBA 051-000768-00
B8 0623 key control conversion board PCBA 051-000766-00
B9 0623 alarm lamp board PCBA 051-000767-00
B10 Touchscreen control board 6800-30-50082
B11 Copper axis encoder board 0010-30-43089
B12 0621 infrared backlight board 051-000259-00
B13 Network interface board 9210-30-30152
B14 0621 valve drive board 0621-30-78634
B15 0616 isolation transformer drive board 051-000036-00
K1 AC power socket /
K2 Lithium battery /
K3 Hardware box radiator fan /
K4 System switch /
K5 Module rack fan /
K6 CIS system /
K7 10.4" inverter /
K8 12.1" inverter /
K9 10.4" display /
K10 12.1" display /
K11 Speaker /
K12 Three-level mechanical switch /
K13 Three-way valve /
K14 Heater /
K15 O2 flush button /
K16 Pneumatic block pressure switch /
K17 ACGO travel switch /
K18 O2 pressure switch at gas supply inlet /
K19 O2 sensor /
