10-26
Figure
No.
Part Number Description Qty FRU
or not?
Remarks
1 115-030838-00
Absorbent canister assembly
(0625)
1 Yes /
2 0601-20-78838 Left hook 1 No 115-030837-00
3 0601-20-78836 Hook ram 2 No
4 0601-20-78827 Lifting tray 1 No
5 M04-051118---
SUS316 countersunk flat head
screw, GB/T818-2000 M3X10
4 No
6 043-006236-00
Lifting device base
(0625/ silkscreen)
1 No
7 M04-021068---
SUS316 single coil spring lock
washer - normal type,
GB/T93-1987 4
3 No
8 M04-021073---
SUS316 plain washer-product
grade A, GB/T97.1-2002 4
3 No
9 M6A-010005---
Flange high abrasion bearing
XFM-0810-09
2 No
10 0601-20-78857 Captive screw 3 No
11 M6M-010068---
Seal, O-ring. 3X1.5, nitrile rubber
A50, black
3 No
12 0601-20-78962 Bearing block 2 No
13 0601-30-78828 BYPASS assembly 1 No
14 M04-051107---
SUS316 cross recessed
countersunk head tapping screw,
FT3X8
4 No
15 0601-20-78812 Linear bearing fixing plate 2 No
16 M04-051108---
SUS316 cross recessed pan head
tapping screw, PT2.6X6
2 No
17 0601-20-78825 Rear rotation block 1 No
18 M04-021067---
SUS316 single coil spring lock
washer, normal type,
GB/T93-1987 3
6 No
19 M04-051123---
SUS316 cross recessed pan head
screw, GB/T818-2000 M3X16
2 No
20 0601-20-78826 Rotation pin 2 No
21 0601-20-78824 Rotation shaft 1 No
22 0601-20-78815 Wheel 2 No
23 M04-021029---
Elastic check ring
GB/T894.1-1986 4 rustproof
nickel plating
3 No
24 0601-20-78835 Holding pin 1 No
25 0601-20-78920 Front rotation block 1 No
26 043-006241-00 Rotation handle (0625) 1 No
27 043-006240-00 Handle fixed seat (0625) 1 No
28 0601-20-78917 Screw 2 No
29 0601-20-78919 Spring 2 No
30 M6B-010001--- Stainless steel ball Φ6 polishing 2 No
31 0601-20-78837 Right hook 1 No
