Mindray Z60T User Manual

2-8 System Overview
 Rear View
 Bottom View
No.
Name
Function
1
Probe holder
Used to place the probe
2 Display Displays the image and parameters during scanning
3
Control Panel
Refer to the 2.6.3 Control Panel
.
4 USB ports Used to connect USB devices
5
Handle
Used to carry the machine
6 I/O Panel
Interface panel used for inputting and outputting signals, refer
to 2.6.1 I/O Panel.
7
Power supply panel
Electrical port panel, refer to 2.6.2 Power Supply Panel.
8
Probe ports
Used to connect the probe
9 Battery cover Used to hold the battery
