Image Optimization 5-1
5 Image Optimization
WARNING:
1.
The images displayed in this system are only reference for
diagnosis. Mindray is not responsible for the correctness of
diagnostic results. It is the responsibility of the clinician,
who performs the exam, to capture the correct diagnostic
results.
2.
In Dual-B imaging mode, the measurement results of the
merged image may be inaccurate. Therefore, the results are
provided for reference only, not for confirming a diagnosis.
5.1 Imaging Mode
Switch the image modes referring “2.6.3 Control Panel”.
5.2 Basic Operations
Before optimizing the image by adjusting image parameters, adjust the brightness and
contrast of the display to the best.
Requirement
Available Operations
To modify the brightness
Adjust gain
Adjust TGC
Adjust [A. power] (do try to adjust gain first before
increasing the acoustic power)
To m odify gray scale image
effect
Adjust [Dynamic Range]
Adjust [Gray Map]
Adjust [Persistence]
Adjust [iClear]
To increase frame rate of gray
scale imaging
Decrease depth
Decrease the [Focus Number] in B mode
Decrease the [FOV] in B mode
Decrease [Line Density]
To increase frame rate of color
imaging
Decrease ROI in Color/Power mode
Turn on [B/C Align] in Color/Power mode
Decrease [Packet Size] in Color mode
Decrease [Line Density]
