Mindray Z60T - Basic Operations of Screens

3-12 System Preparation
3.11.2 Basic Operations of Screens
Composition
Description
Title Bar
The title bar is used to give a description for the content and
function of the screen.
Page Tab
Use the selection pointer and <Set> key to open / close the
available pages.
Content
 Radio button: click to select the item.
 Check box: click to check or uncheck the item.
 Entry box: enter characters manually via the keyboard. .
 Drop-down list box: click [▼] to show the list and select
an item.
[OK] and [Cancel]
When the operation of a screen is complete, press the [OK]
or [Cancel] button to save or cancel the operation, and close
the screen.
To reposition a dialogue box:
1. Roll the trackball to move the cursor onto the title bar of the dialogue box. At this time the
cursor becomes a
; press the [Set] key.
2. Roll the trackball and reposition the rectangular graphic to the new desired location.
3. Press the <Set> key, and the dialogue box is moved to the desired position.
Title
Ta b
Control
button
Contents
