Mips Technologies Malta - Table 3.10 LEDBAR Register

Memory Map
18 MIPS® Malta™ User’s Manual, Revision 01.07
Copyright © 2000-2007 MIPS Technologies Inc. All rights reserved.
ASCIIPOS0 0x0000.0018 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘0’, which is the left-most positioned
character.
ASCIIPOS1 0x0000.0020 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘1’.
ASCIIPOS2 0x0000.0028 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘2’.
ASCIIPOS3 0x0000.0030 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘3’.
ASCIIPOS4 0x0000.0038 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘4’.
ASCIIPOS5 0x0000.0040 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘5’.
ASCIIPOS6 0x0000.0048 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘6’.
ASCIIPOS7 0x0000.0050 WO Writing an ASCII value to this regis-
ter updates ASCII display position
‘7’, which is the right-most posi-
tioned character.
Name: LEDBAR
Address: 0x1F00.0408
Access: R/W
Reset Value: 0x00
Table 3.10 LEDBAR Register
Bits Field Name Function Initial Value
31:8 Reserved Reserved 0
7:0 BAR 8 bits each corresponding to 1 LED (1 = ON) 0x00
Name: ASCIIWORD
Address: 0x1F00.0410
Access: WO
Reset Value: n/a
Table 3.9 Display Registers. BASE = 0x1F00.0400 (Continued)
Register Name Offset Address Access Function
